Technical Specifications :

·      Processor Support : Support Intel® Socket 1150 for 4th Generation Core™i7/ Core™ i5/Core™ i3/Pentium®/Celeron® Processors;

·      Chipset : Intel® H81 Chipset;

·      BIOS : AMI BIOS;

·      Memory Support : 2 x DDR3 1066/1333/1600MHz DIMMs

·      Slots : 1 PCI Express x16 slot

·      LAN : Realtek Chip, 1 x 100M

·      Audio : Chip integrated by Realtek®662, Flexible 6-channel

·      Storage : 4 x SATA 6Gb/s Ports

·      USB : 4 x USB 3.0 port (2 at back panel, blue, 2 at mid-board) 6 x USB 2.0 port (4 at back panel, black, 2 at mid-board)

·      Back panel : 1 x VGA Port, 1 x HDMI Port, 1 x LAN (RJ45) Port, 2 x USB 3.0 Ports (Blue), 4 x USB 2.0 Ports, 3 x flexible audio jacks

·      Onboard Interface : 1 x USB 3.0 connector (19pin) supports 2 x USB 3.0 ports, 1 x USB 2.0 connector supports 2 x USB 2.0 Ports, 4 x SATA 3Gb/s Ports, 1 x NVMe Slot, 1 x 4 -pin CPU_FAN/SYS_FAN connectors, 1 x 24-pin ATX power connector, 1 x 4-pin 12V ATX Power connectors, 1 x F_Audio connector, 1 x F_Panel connector

·      Form Factor : Micro-ATX

 Warranty : 3 Years
